Thermal Imaging Camera with 240 x 240 TISR Detail, 25Hz Refresh and -4°F to 842°F Range – TOPDON TC004 Mini

A thermal imaging camera helps reveal temperature differences during home, HVAC, electrical, machinery and vehicle inspections. TOPDON TC004 Mini starts with a 128 x 128 thermal sensor and uses TISR enhancement for 240 x 240 image detail with a smooth 25-hertz refresh rate.

Automatic hot, cold and center-spot readings speed up scanning, while adjustable alerts warn when a preset temperature is exceeded and can capture a photo. The pocket-size camera stores up to 8,000 images, offers five color palettes and runs for up to 15 hours.

Specifications

• Brand: TOPDON
• Model: TC004 Mini
• Native thermal resolution: 128 x 128
• TISR image resolution: 240 x 240
• Refresh rate: 25 Hz
• Field of view: 40° x 30°
• Temperature range: -4°F to 842°F / -20°C to 450°C
• Listed accuracy: ±3.6°F or ±2%
• Palettes: White Hot, Black Hot, Iron, Rainbow and Red Hot
• Storage: 512 MB eMMC / up to 8000 photos
• Runtime: Up to 15 hours
• Protection: IP54 and 2 m drop resistance
